Arc Stick

Color Available

Product Description

Senses Akustik arc stick is a wall system composed of modular planks that assemble to create customisable patterns, yielding a continuous, acoustically absorptive architectural finish. Arc stick has five distinct half round modules that are composed of felt/fabric- covered acoustic substrate available in standard patterns. Got your own ideas! this clever acoustic system allows one-of-a-kind patterning by switching up plank widths and range colours of felt/fabric.
  • Arc Stick 1.1
  • Arc Stick 1.2
  • Arc Stick 1.3
  • Arc Stick 1.4

Material Properties

  • Easy to machine
  • Robust and shockproof
  • Very high colour fastness of the all-round homogeneous surface available in 24 colors of colorline
  • Alkalinity: pH: 7.8 (pH 7 is neutral)
  • Melting point: 250 °C
  • Decomposition Temp: > 250 °C

Specifications

Content

Felt/ Fabric, Foam, Birch ply

Dimension

Height 2700 MM
Width A 100 MM, B 150 MM, C 200 MM, D 250 MM, E 300 MM

Material

35MM (±10%)

Fixing System

Interlock mounting system

Light Fastness

ISO 105-B02-1994 (>7)

Flammability

Class 1 or A

Smoke Development Index

288

VOC Emissions

ASTM D5116 (<0.5mg/m2/h)

Environmental

100% PET contains no formaldehyde, biodegradable, VOC free, No chemical
irritants, recyclable and free of harmful substances.

Environment
Component Kit

Senses Akustik - Arc Stick

Origin

India


Cleaning and Handling

Surface Disinfection
Spray disinfectants can be used for rapid surface disinfection.

Surface Duster/Vacuum Cleaner
For dusting use duster or vacuum cleaner.

Sparkling Water
For slight contaminationation apply sparkling water to polluted area. Wipe carefully with a sponge.

Upholstery Cleaner
For medium contaminationation apply upholstery cleaner to polluted area. Wipe cafefully with a sponge.


Material Finishes and Variations

Acoustical material is produced by felting 100% PET (60% recycled). in some colors, a beautiful heathering pattern becomes visible as a result of this traditional manufacturing process, and will result in natural variations in color and patterns from batch to batch and sheet to sheet.

Acoustic Performance

  • Senses Akustik 12 mm panel is ideal for high frequency absorption and achieves an NRC 0.55 when panel is directly fixed to a wall on base surface.
  • Senses Akustik 24 mm panel is ideal for medium and high frequency absorption and it achieves 0.80 NRC when panel is directly fixed to wall on a base surface.
  • The sound absorption has been tested in accordance with as/ISO 354. complete test report will be available on request.



Sound Absorption

  • 12MM Panel NRC= 0.45 (00 MM Air gap)
  • 24MM Panel NRC= 0.80 (00 MM Air gap)
