Home   >   Products   >   Echo Brick
Acoustic Walls

Echo Brick

Color Available

Product Description

Senses Akustik Echo Punch is a very handy, extremely lightweight product, designed to delimit areas in a pleasant and colourful way, Increasing acoustic comfort. Just because of its aesthetic value, echo punch is also strongly demanded in wall and ceiling areas.
  • Standard Module

Material Properties

  • Easy to machine
  • Robust and shockproof
  • Very high colour fastness of the all-round homogeneous surface available in 15 colors of felt
  • Alkalinity: pH: 7.8 (pH 7 is neutral)
  • Melting point: 250 °C
  • Decomposition Temp: > 250 °C

Specifications

Content

Felt, Polyester Foam

Dimension

690mm X 1200mm

Material

Thickness: 20 MM (±10%).
Weight: 2.5 Kg/ Module

Fixing System

Velcro/ Adhesives

Light Fastness

ISO 105-B02-1994 (>7)

Flammability

Class 1 or A

Smoke Development Index

288

VOC Emissions

ASTM D5116 (<0.5mg/m2/h)

Environmental

100% PET contains no formaldehyde, biodegradable, VOC free, No chemical irritants, recyclable and free of harmful substances.

Environment
Component Kit

Senses Akustik - Echo Punch

Origin

India


Cleaning and Handling

Surface Disinfection
Spray disinfectants can be used for rapid surface disinfection.

Surface Duster/Vacuum Cleaner
For dusting use duster or vacuum cleaner.

Sparkling Water
For slight contaminationation apply sparkling water to polluted area. Wipe carefully with a sponge.

Upholstery Cleaner
For medium contaminationation apply upholstery cleaner to polluted area. Wipe carefully with a sponge.


Material Finishes and Variations

Acoustical material is produced by felting 100% PET (60% recycled). in some colors, a beautiful heathering pattern becomes visible as a result of this traditional manufacturing process, and will result in natural variations in color and patterns from batch to batch and sheet to sheet.

Acoustic Performance

  • Senses Akustik 12 mm panel is ideal for high frequency absorption and achieves an NRC 0.55 when panel is directly fixed to a wall on base surface.
  • Senses Akustik 24 mm panel is ideal for medium and high frequency absorption and it achieves 0.80 NRC when panel is directly fixed to wall on a base surface.
  • The sound absorption has been tested in accordance with as/ISO 354. complete test report will be available on request.



Sound Absorption

  • 12MM Panel NRC= 0.45 (00 MM Air gap)
  • 24MM Panel NRC= 0.80 (00 MM Air gap)
